Efficient Power Management
Flexible and Stable Structure
Smart Traffic Monitoring
Safety and Security
| Model | TVMS-20M-SMD | TVMS-25M-SMD | TVMS-31.25M-SMD |
| Pixel Pitch (mm) | 20 | 25 | 31.25 |
| LED Type | SMD | ||
| Module Resolution (pixels) (HxW) | 8x16 | 200x400 | 250x250 |
| Module Size (mm) (HxW) | 160x320 | 200x400 | 250x250 |
| Maximum Resolution for Trailer Mounted VMS (pixels) (HxW) | 48x80 | 56x96 | 64x96 |
| Maximum Size for Trailer Mounted VMS (mm) (HxW) | 960x1600 | 1400x2400 | 2000x3000 |
| Cabinet Dimension (mm) (HxWxD) | 1160x1800x120 | 1600x2600x120 | 2085x3200x180 |
| Display Color | Single or Full Color | ||
| Brightness | Red > 3100 cd/m², Green > 3720 cd/m², Yellow > 7440 cd/m², White > 12400 cd/m² | ||
| Physical Characteristics | |||
| Enclosure Structure | Aluminum Housing with Waterproof Modules | ||
| Working Temperature | -25℃ ~ +60℃ | ||
| Humidity Range | RH<95% | ||
| Ingress Protection Class | IP65 | ||
| Maintenance Access | Front | ||
| Electrical Specifications | |||
| Solar Power System | DC 12V | ||
| Sensor | Light Sensor | ||
| Communication | RS232 / RS485 / Ethernet Via RJ45 / 3G / 4G / 5G | ||
| Protocol | NTCIP 1203 / MODBUS / UTMC / XML / Jetfilell / Profibus / RSMP / HTTP / API | ||
| Trailer Specifications | |||
| Spraying Process | Hot Dip Galvanized / Electrostatic Powder Spraying | ||
| Lifting System | Hydraulic Lifting System | ||
| Trailer Size | Type-A: 1750mmx2250mm | Type-B: 2050mmx2450mm | Type-C: 2050mmx3550mm |
| Total Weight of Trailer and VMS | Type-A: About 700KG | Type-B: About 1000KG | Type-C: About 1200KG |
