Clear Lens Countdown Timer Traffic Light

  • Clear Lens Countdown Timer Traffic Light

Clear Lens Countdown Timer Traffic Light


Introduction:
Clear Lens 2.5 Bi-color Countdown Timer Traffic Light

Model : JXK301





  • Application – urban light signaling
  • Wide operating voltage
  • Transparent polycarbonate optical lens – impact resistant
  • Anti-phantom effect minimized, optimal viewing angle
  • High intensity LED light source – low energy consumption
  • 5mm LED (DIP) by EPISTAR
  • Long life cycle – more than 80,000 working hours
  • Highly durable polycarbonate housing, UV-light resistant
  • Modular design – easy installation and maintenance
  • Fixation system with L-shape mounting brackets
  • Self-learning firmware for the fixed time control mode
200mm led traffic light
Working Voltage AC85V-265V, 50/60 Hz Working Temperature -40℃  ~ +80℃
Vibration Resistance Acc.to EN60068-2-64:2007 Damp Heat Resistance Acc.to EN60068-2-30
Housing Material PC -- UV resistant Impact Resistance IR 3 Acc.to EN12368
View Angle L/R-30° U/D-30° View Distance ≥ 300m
LED brand EPISTAR Warranty 5 years

Color LED Qty Intensity Wave length Power Consumption
Red 74pcs R≥15000cd/m² 620-630nm ≤8W
Green 74pcs G≥35000cd/m² 503-508nm ≤8W
